3A-EPG Molecular Sieve

Home » Products » Special Molecular Sieve » 3A-EPG Molecular Sieve
3A-EPG Molecular Sieve

K12 [(AlO2)12(SiO2)12].XH2O

3A-EPG molecular sieve is specialized for the deep dry of pyrolysis gas in ethylene industry. It features high stability and low abrasion rate, providing the longest life and minimum pressure drop in use.

Properties Unit Pellet Trisiv
Particle Sizes inch 1/16” 1/8” 1/8” 1/4”
Particle Diameter mm 1.6-1.9 3.2—3.5 2.8-3.2 6.4-6.7
Bulk Density g / ml ≥0.64 ≥0.64 ≥0.65 ≥0.64
Crush Strength N ≥35 ≥75 ≥70 ≥140
CO2 Capacity wt, % ≤1.0 ≤1.0 ≤1.0 ≤1.0
Heat of absorption KJ/kg H2O ≤4186 ≤4186 ≤4186 ≤4186
Equilibrium H2O Capacity wt, % ≥20.5 ≥20.5 ≥20.5 ≥20.5
Moisture Content wt, % ≤1.5 ≤1.5 ≤1.5 ≤1.5

Molecules adsorbed Molecules with an effective diameter of < 3 angstroms, e.g., H2O
Molecules excluded Molecules with an effective diameter of >3 angstroms, e.g., C2H4, CO2, and CH3OH
Measured at17.5 mmHg and25 °C. The normal equilibrium water capacity in water saturated gas

Representative packaging
We put 3A molecular sieve in a sealed iron drum with the net weight of 125 Kg.

As a China-based 3A-EPG molecular sieve manufacturer, we provide not only 3A molecular sieve, but also 13X molecular sieve, 3A-ETH ethanol dehydration molecular sieve, compressed air drying activated alumina, among others.
